The FABIKE frame set


No limits to your creativity.

SCROLL DOWN

The FABIKE frame set


No limits to your creativity.

The FABIKE is a Flexibly Adjustable Bike.

The FABIKE frame set is the first step in creating the cycling experience you've always wanted. Our mission is to introduce a new category into the bicycle market.
The frame set can be configured into a road bike, an urban bike, an off-road bike and more, without compromising on sleek Italian design, the latest technology and lightweight materials.
We think of the FABIKE as an uncompromising way to effortlessly design your own ride, and we believe that the future of cycling is flexibility.


Specifications

Frame: FABIKE Frame, Toray T800 carbon fiber
Fork: FABIKE Fork, Toray T800 carbon fiber
Head set: FABIKE headset 1-1/8" 1-1/2"
Seat clamp: FABIKE seatclamp
Seat post diameter: 31,6mm
Brakes: FABIKE Brakes
Bottom bracket: Press Fit 30
Weight (complete frame set): 1.9 Kg

The FABIKE frame set is available in 5 different sizes and 5 colors. The color chosen will also affect the color of the sliding dropouts, the three-dimensional logo on the head tube, the headset and the seat clamp.




Dropouts

The FABIKE dropouts have been designed in an all-new way.
This innovation allows you to switch from 120mm to 130/131mm rear-hub spacing, giving you the flexibility to mount either a single-speed or cassette hub onto the frame. Our dropouts also utilize a sliding vertical insertion, allowing you to mount the rear wheel as easily as on a regular road frame. This can be done without a chain tensioner, should you decide to use your bike as a single-speed.
Horizontal movement is regulated (and restricted) by an integrated micro-adjustment wheel which ensures a perfect fit. The FABIKE dropouts are also belt-drive ready and produced using CNC machinery. Made out of 7075-T6 aluminum alloy, the FABIKE dropouts come with titanium locking bolts and nuts.

NOTE: to fit a cassette wheel into the FABIKE dropouts you will need a longer QR, usually used for MTB.

More Clearance

The FABIKE fork, chain-stay and seat-stay are designed as a compromise between a road bike and a cyclocross bike.
At first glance, it can be difficult to spot the differences between the FABIKE and a standard road bike, both in terms of look, and weight.
A closer inspection reveals that the FABIKE frame set is able to welcome a much larger tire than a standard road bike, up to a maximum size of 700x35mm. This means that the FABIKE can ensure an easy and comfortable ride, regardless of the surface you’re riding on.

Internal cable routing

The FABIKE frame features fully-internal cable routing. This means that even in the bottom bracket area, the cables always stay inside the frame. This is more than just an aesthetic choice, as the cables will be protected from the elements, allowing the bike to perform better in all conditions.


Geometry


IMPORTANT: The value “H” represents the maximum depth that the seat post can go inside the frame. Forcing the seat post passed the maximum depth may cause damage to the frame.

IMPORTANT: The value “H” represents the maximum depth that the seat post can go inside the frame. Forcing the seat post passed the maximum depth may cause damage to the frame.


Pricing

For Europe Taxes included
Outside Europe Taxes not included

The price includes: frame, fork, brakes, headset, seat clamp, and all the spare parts needed to create every possible configuration.

If you have a custom build in mind, we'd be happy to discuss it and do our best to make it happen!


The Components


Another essential part of a great cycling experience.

SCROLL DOWN

The Components


Another essential part of a great cycling experience.

Flip-Flop Hub

Our hub has been designed as an updated fixed/free-wheel hub. The improvement comes from the inclusion of an internal free-wheel on the free-wheel side. On both the fixed-wheel and free-wheel side, the same sprocket (with a nine spline standard) can be used. This saves on weight, and also allows for greater ease of use.

Material: alloy 7075-T6 axle, alloy 6061-T6 body
Spacing: 120mm
Chainline: 42mm (on both sides)
Drilling: 32h
Weight: 270g

The FABIKE flip-flop hub comes in white, with the same 5 color options for the washer bolts: red, yellow, green, blue and silver.

Cassette Wheelset

The FABIKE Cassette wheel set is suitable both for road and off-road use, as its alloy rims are wide enough to accommodate bigger tires.

Front wheel: 20 spokes straight pull
Rear wheel: 24 spokes straight pull
External rims width: 22mm
Internal rims width: 17mm
Rims hight: 27mm
Wheel set weight: 1,450g

Nipples can be ordered in the standard FABIKE colors: red, yellow, green, blue and silver.





CCS Chainring

The FABIKE CCS Chainring has been engineered as a single front chainring. The difference from a standard chainring is our "Corrective Chainline System".

Our chainring is designed to "move" the chainline of a standard double road crankset towards the center. The result is much better alignment between the single chainring and the sprocket/cassette.

Material: alloy 7075-T6, CNC machined
Number of theef: 46
Chainline offset: 3.5 mm
BCD: 130mm
Weight: 75g




Brake Levers

The FABIKE brake levers are "three finger" levers with an extremely minimalist look. They are also reversible, which means that each lever can be used on either the left or right side.

Material: alloy 6061-T6, CNC machined
Clamp diameter: 22.2mm or 31.8mm
Weight: 35g/lever (22.2mm clamp)



* Price per individual lever.

Brakes

The FABIKE brakes we made to perfectly fit the FABIKE fork and chainstay. They are placed at the back of the fork and on the underside of the bottom bracket area. They have the braking power of traditional V-brakes, but are more aerodynamic and are consistent with the minimal design of the FABIKE.

Material: alloy 7075-T6, CNC machined
Weight: 150g per wheel

* Price per individual brake.


About


Italian design, international team.

SCROLL DOWN

About


Italian design, international team.

The FABIKE project started in 2011. The founder of the company and driving force behind the FABIKE brand is Fabio Putzolu. He comes from a family with a long tradition in cycling and grew up around passionate cyclists. In fact, the real inspiration of the FABIKE project is Fabio's uncle Antonino, who in the early 50's was already spreading the cycling passion in Sardinia - Italy.

For many years Fabio studied and worked in design and advertising, and is thrilled to combine so many of his passions under one roof. After many developments, three prototypes, and countless sleepless nights over two years, the FABIKE was ready to hit the road.
As the project grew and developed, Jake and Alexey joined the team, bringing a wealth of diverse experience. In August 2013 the FABIKE was officially presented to the public at Eurobike, the largest cycling trade show in the world.

Since then, we have continued to work passionately, improving our product day after day, spreading our vision of what a modern bicycle could be, worldwide.

We strongly believe the future of cycling is flexibility, and we welcome you to join us on our journey.



Fabio Putzolu

Founder and Chief Designer

ITALIAN
Living around the World

Jake Zahradnik

Sales Director, Western Region

CANADIAN
Living in Prague

Alexey Statsenko

Sales Director, Eastern Region

UKRAINIAN
Living in Prague

Matteo Putzolu

Financial Director

ITALIAN
Living in Vienna

Beppe Piras

Urban Mobility Consultant

ITALIAN
Living in Italy
